ABYC Fire Extinguisher Guidelines - PassageMaker

ABYC Fire Extinguisher Guidelines

Author:
Publish date:

Gearhead: Portable Fire Extinguishers Web Extra

ABYC GUIDELINES FOR FIXED FIRE EXTINGUISHERS FOR BOATS 65 FEET OR LESS IN LENGTH

Type of Boat

No. Of Extinguishers

USCG Type (see note 1)

ANSI/UL 711 Type (see notes 2&3)

Location

Open boats under 16

1

B-1

ABC

steering position

Open boats over 16ft. in length

2

B-1

ABC

steering position and galley or passenger cockit

Boats under 26ft. in length

2

B-1

ABC

steering position and galley (see note 4) or passenger cockpit

Boats 26 ft. to under 40 ft. in length

3

B-1

ABC

outside engine compartment steering position adn gallery (see note 4), or passenger cockpit

Boats 40 ft. and over, but not over 65 ft. in length

4

B-1

ABC

outside engine compartment, steering position, crew's quarters, and galley (see Note 4) or passenger cockpit


Notes:
1. If a discharge port is installed (ABYC A-4.5.2.2), a USCG Type B-I portable fire extinguisher may not be adequate.
2. Extinguishers intended for engine compartment protection in accordance with A-4.5.2.2 or A-4.6.4 are not required to have a Class A rating.
3. Boats under 26 feet in length without enclosed accommodation spaces or enclosed galleys may be equipped with a bucket with attached lanyard and a Class BC-rated extinguisher in lieu of Class ABC-rated portable fire extinguishers.
4. On boats having galley stoves, one of the required extinguishers shall be readily accessible thereto.
